Freewing A-6 Intruder 80mm EDF Jet ARF Version RC Airplane
1.it requires 3530-1750KV brushless outrunner motor
2.it requires 6 Channel Radio,6 Channel Receiver
Note:
If your shipment is delivered to a remote area,this charge will be added to your shipping cost.Checking your area is a remote area or is not a remote area on the website:http://remoteareas.dhl.com/jsp/first.jsp
During its service life, the Grumman A-6 Intruder was the US Navy and Marine Corps premier close combat, mid-wing attack aircraft. The Intruder was in service between 1963 and 1997 and was designed as an all-weather medium attack aircraft to replace the piston-engined Douglas A-1 Skyraider.
We are proud to offer such a historic plane as our first 12 blade 80mm EDF offering. The A6 Intruder is easily one of the most requested models, so we wanted to offer an EDF jet that would stand apart from its competitors. As you've come to expect from Freewing Model manufacturer in China, the A6 intruder is loaded with scale features and performance componentry. The new 80mm 12-blade EDF with metal housing powered by a powerful 1750kV motor produces nearly 6 pounds of thrust for awesome speed and incredible maneuverability. The sound produced from the 12 blade EDF will simply blow you away.
While 5 and 6 blade EDF produce a high pitched whining sound, the 12 blade EDF with metal housing produces the "whoosh" and air crushing sound similar to a gas turbine jet. Additional upgraded features include a 80A Hobbywing ESC, 9g precision servos, electronic retracts with full metal shock absorbing struts, and scale drop down flaps. Own one of the most sought after, highly detailed, best built RC foam jet on the market - the Freewing A-6 Intruder.
FEATURES:
- Model officially licensed by Freewing Model in China.
- 12 Blade factory balanced EDF with metal housing combined with 3530-1750KV brushless outrunner motor produces realistic jet turbine sound and an incredible 6 lbs of thrust
- Composite fan blades combined with metal EDF housing make the A6 AMA compliant (the fan blades themselves are NOT metal, so there are no flying restrictions)
- Super scale details include two hand painted pilots, full instrument panel, refueling probe, scale drop tanks, airfoil panel lines, and complete USS Forrestal graphics package
- Optional weapons set can be added for increased realism
- 80 Amp Hobbywing ESC with 5A BEC
- Electronic retractable landing gear with all metal shock-absorbing struts
- Steerable, shock absorbing nose gear for enhanced ground maneuverability
- Full function drop down flaps allow shorter take-off distances and slow, scale landings
- Full function linked horizontal stabilizer/elevator gives incredible climb and descent capability and true to life scale detail
- Carbon spars and EPO foam construction provide the perfect balance between strength and flexibility
- Nylon hinges on all control surfaces (superior to foam hinges)
REQUIRES:
- Outrunner motor, servos, ESC
- 80 Amp Hobbywing ESC with 5A BEC
- 6 Channel Radio - Select a minimum 6 channel radio
- 6 Channel Receiver - Select a minimum 6 channel receiver
- 6 Cell 22.2V 4000 mAh LiPo Battery with EC5 connector
- 6 Cell Compatible Battery Charger - Select a minimum 6 cell (6S) charger
Package detaisl:
- there is no Outrunner motor, no servos,no ESC in the package
- Freewing A-6 Intruder 80mm EDF Jet Kit RC airplane
- English User manual
- there is no any electronic parts in the package
PRODUCT SPECIFICATIONS:
Wingspan |
1170mm / 46in |
Length |
1200mm / 47.2in |
Flying Weight |
2260g / 79.7oz |
| CG (Center of Gravity) | check manual |
Power System |
3530-1750kV Brushless Outrunner Motor |
Electronic Speed Control |
80A ESC, 5A BEC, EC5 Connector |
Propeller / EDF |
80mm Metal EDF with 12 Blade Fan |
Servos |
9g metal gear standard with 100mm lead : nose gear steering |
| Landing Gear | Electronic retractable main gear and steerable nose gear with all metal shock absorbing struts |
Required Battery |
6S 22.2V 4000mAh 60C LiPo |
Required Radio |
6 Channel |
| Ailerons | Yes |
Elevator |
Yes |
| Rudder | Yes |
Flaps |
Yes |
Lights |
No |
Hinge Type |
Nylon hinges |
| Material | EPO Foam |
| Skill Level | Intermediate |
| Build Time | 2 Hours |
| Recommended Environment | Outdoor |
